Real time pcr system, PCR-Q32 Series
|
|
|
Description
This product adopts four channel and double 16-well blocks，which can run two different files simultaneously. The product combines a variety of advanced technologies;7-inch high-definition TFT color touch screen, Win10 operating system with analysis software, complete quantitative analysis and printing report without computer. It adopts American Marlow custom-made peltier，high sensitivity photoelectric detector and side scan technology，to ensure superior performance and stable detection results.
This product adopts four channel and double 16-well blocks，which can run two different files simultaneously. The product combines a variety of advanced technologies;7-inch high-definition TFT color touch screen, Win10 operating system with analysis software, complete quantitative analysis and printing report without computer. It adopts American Marlow custom-made peltier，high sensitivity photoelectric detector and side scan technology，to ensure superior performance and stable detection results.
Advantages
- Four channels and double 16-well blocks design, can run twodifferent programs at the same
- Small size， light weight， easy to carry.
- Powerful software analysis function，which can be used forQuantitative Analysis，Melting Curve Analysis， Genotyping，7-inch high-definition TFT color touch screen，and embedded Win 10 operating system.
- 20G flash memory can save 40，000 experimental data.
- Printer as an optional which can print the records directly, noneed to connect the computer.
- Imported 32 bundled optical fibers are used to collectfluorescence from the side to increase the intensity of fluorescence signal and reduce light conduction damage.
- Black reaction block to avoid background noise.
- LED light source has the advantage of energy saving，environmentalprotection， long service life and maintenance free.
- The electromagnetic lock cover technology prevents the hot lidfrom accidentally opening.
- Front shutdown button makes file data more secure.
- Constant current control circuit makes power output smooth andextends Peltier life， also improves temperature control accuracy; It has the protection functions of over-current,over temperature，power-off data self recovery,
- Forward and backward air vent design, can be placed side byside， saving laboratory.
|
Specification
Model Sample Capacity Consumable Reaction Volume Temperature control technology Temperature Range MAX. Ramp Rate Temperature fluctuation Uniformity Accuracy Hot Lid Temperature Temperature Control Excitation Wavelength Emission Wavelength Factory Calibrated Dyes Excitation Detection Dynamic Range Sensitivity Feature function Date Export Formats Printing Control Method Communication Dimension (L×W×H) Net Weight Electricity |
PCR-Q32-4F 32×0.2ml(4×8well, dual block) Clear 0.2 ml PCR tube /8-tube strips 15-100μL Marlow customized Peltier allow 1,000,000 cycles 0-100℃ (Resolution：0.1℃) 8℃/s ±0.1℃ ±0.25℃ ±0.25℃ 30-110℃((Adjustable, default 105℃)) Block/Tube 460—628nm F1: 520-540nm F2: 540-580nm F3: 571-612nm F4: 628-692nm F1：FAM/SYBR Green I; F2：HEX/VIC/JOE/TET F3: ROX F4: CY5 Long life LED High sensitivity photoelectric detector 1-1010 Copies 1 copy Quantitative/qualitative analysis， Melting curve， Genotyping Excel, CSV, txt Report can be printed (optional USB thermal printer) 7 inch color TFT touch screen， Can be connected to computer control USB2.0 300×267×198mm 11Kg 220VAC、50Hz ; DC29V 600W |
